Electrical Miniature Slip Ring for Stage Lighting
Rotating Stage Lighting
Miniature Slip Ring
Capsule Slip Ring
OD 12.4mm, 2*5A+3*2A
OD 15.5mm, 2*15A+4*2A
OD 22mm, 12*2A without flange
OD 22mm, 2*10A+5*2A
Featuress
• Integrate signal transmission
• Terminal plug for option
• Gold to gold contact
Electrical miniature slip ring overview
Electrical miniature slip ring is an important part of modern industrial system, while prevent equipment winding. 360° rotation conductive and signal transmission. If you pay attention to observe, you can find electrical slip rings in various scenes around us.
Rotating stage lighting slip ring application
We believe that everyone is familiar with rotating stage lighting.
Chasing light: It is an important lighting fixture in stage lighting, with characteristics such as high brightness and clear light spots. We can change the irtual and real light spots by adjusting the focal length. Equipped with a movable light bar for easy color change, the lamp body can operate freely. There are two types of taillights: mechanical taillights and computer taillights.
Spotlight: It is one of the core lighting fixtures in stage lighting, commonly available in 1KW and 2KW specifications, with 2KW having the highest usage rate. The beam of the spotlight is concentrated and the edge of the spot is clear, which can highlight local key points or enlarge the spot to illuminate specific areas. We use it as a light source for face light, slap light, side light and other purposes.
According to the current rotating stage lights move by the rotating of the motor to turn the lamp body. Usually the rotation speed is fast, the internal wire is easy to wrap. So why do the electrical slip rings use on the rotating stage lighting recommend miniature slip rings? Because the height and lateral space of the chasing light rotating lighting equipment have installation limitations, it is difficult to apply ordinary slip rings and through hole slip rings.
Mini slip ring is good for narrow axial installation space customized for small limited equipment, integrated signal slip ring construction. The OD of the conductive slip ring is extremely thin, the size OD can reach 6 mm, combined with control signals. The stage lighting equipment requirements of the slip ring size is small and the speed is fast.
The capsule slip ring is small, light, low torque, low wear, low electrical noise, long life and other main characteristics. WayDun slipring following technical advantages:
1, The standard micro slip ring can provide 1~72 channels, 2~30A current/signal, rated voltage up to 380V. And working speed up to 300rpm optional. While meet the equipment stable and 360 degrees rotational conduction and signal transmission.
2, Stage lighting slip ring surface is gold-plated, has high reliability, can transmit a variety of special signals, is the end of the axial space small instrument equipment good choice.
3, With ultra-small outer diameter size, make full use of limited installation space.
4, For rotary lighting equipment design has WDM-01205, WDM02208S, WDM-02216, with speed, low friction, low contact resistance and other characteristics. WayDun slip rings have been successfully applied In the field of stage lighting, rotating platform, rotating light box, chasing light, spotlight, etc.
According to the needs of different equipment, WayDun can supply capsule slip ring, through hole slip ring, pancake slip ring, etc. As well as can integrate Ethernet signal, USB signal, optical fiber signal, RF signal and other special signals.
We happy to provide customers with professional and cost-effective 360° signal transmission solutions.
