Paper Making Rotary Union Series
● PS paper making rotary union special for high-speed paper machines in the papermaking industry. The ring bracket supports the rotary joint and the installation is stable.
● Anti-spherical sealing design, four times stronger than ordinary spherical sealing rings
● Rotary joint special siphon, suction nozzle height adjustment device, precise control of the distance between the suction nozzle opening and the cylinder wall
● Spring compensation package structure makes maintenance easier
● Comes with a sight glass to observe condensation discharge conditions
Please contact us immediately if you have special needs, our sales engineers can recommend slip ring models or design customized slip rings for you.
Technical Parameter
Max Speed:800 r/min
Temperature:-30℃～+235℃
Max Pressure:1.1Mpa
Media: Steam
Papermaking Rotary Union Notes
● Rotary Joint Connector Manufacturer Specifically designed for the paper making industry
● For high temperature paper making rotary union, please reach out to WAYDUN for further information
This type of rotary joint / rotary union is mainly used in high speed papermaking industry.
Of course, just send us an email with inquiry.
We focus on custom slip ring for 10 years. Cases can be provided for reference.
We are very good at one-to-one communication for complex slip ring or rotary joint products, based on our experience. If you can’t find a suitable supplier for your custom case, please try us.
