| Parameters | Values | |||
| RF channel | 1 | 2 | 3 | 4 |
| Interface | SMA-F(50Ω) | SMA-F(50Ω) | SMA-F(50Ω) | SMA-F(50Ω) |
| Frequency range | 0-4GHz | 0-4GHz | 0-4GHz | 0-4GHz |
| Input power (min) | 50W | 50W | 50W | 50W |
| Standing wave ratio (max) | 1.5dB | 1.5dB | 1.5dB | 1.5dB |
| Standing wave ratio fluctuation (max) | 0.1dB | 0.1dB | 0.1dB | 0.1dB |
| Insertion loss (max) | 1dB | 1dB | 1dB | 1dB |
| Isolation degree (min) | 55dB | 55dB | 55dB | 55dB |
| Estimated life cycle | 5 million | |||
| IP rating | IP65 | |||
| Maximum speed | 60RPM | |||
| Working temperature | -40℃~+65℃ | |||
| Storage temperature | -50℃~+70℃ | |||
| Material | Stainless Steel | |||
