| Parameters | Values | ||
| RF channel | 1 | 2 | 3 |
| Interface | SMA-F(50Ω) | SMA-F(50Ω) | SMA-F(50Ω) |
| Frequency range | DC-8GHz | DC-8GHz | DC-8GHz |
| Average power (max) | 10W | 10W | 10W |
| Standing wave ratio (max) | 1.5dB | 1.5dB | 1.5dB |
| Standing wave ratio fluctuation (max) | 0.1dB | 0.1dB | 0.1dB |
| Insertion loss (max) | 1.3dB | 1.3dB | 1.3dB |
| Insertion loss fluctuation (max) | 0.15dB | 0.15dB | 0.15dB |
| Isolation degree (min) | 70dB | 70dB | 70dB |
| Phase stability (max) | ±3° | ±4° | ±4° |
| Estimated life cycle | 5 million | ||
| IP rating | IP65 | ||
| Maximum speed | 60RPM | ||
| Working temperature | -40℃~+65℃ | ||
| Storage temperature | -50℃~+70℃ | ||
| Material | Stainless Steel | ||
