| Parameters | Values | |||||
| RF channel | 1 | 2 | 3 | 4 | 5 | 6 |
| Interface | SMA-F(50Ω) | |||||
| Frequency range | 0-8GHz | 0-8GHz | 0-8GHz | 0-6GHz | 0-6GHz | 0-6GHz |
| Standing wave ratio (max) | 1.5dB | 1.5dB | 1.5dB | 1.6dB | 1.6dB | 1.6dB |
| Standing wave ratio fluctuation (max) | 0.1dB | |||||
| Insertion loss (max) | 1.4dB | 1.4dB | 1.4dB | 1.5dB | 1.5dB | 1.5dB |
| Insertion loss fluctuation | 0.15dB | |||||
| Isolation degree (min) | 70dB | |||||
| Estimated life cycle | 5 million | |||||
| IP rating | IP65 | |||||
| Maximum speed | 60RPM | |||||
| Working temperature | -40℃~+65℃ | |||||
| Storage temperature | -50℃~+70℃ | |||||
| Material | Stainless Steel | |||||
